It is an advanced lightweight fuel tank. It uses a polymer or plastic inner liner and a carbon-fiber- reinforced outer wrap. It contains no metal in its structural shell.
Type 4 CNG cylinder cascade is an assembly of multiple high-pressure gas cylinders connected together by a common manifold to store and dispense natural gas efficiently. Built with non-metallic liners fully wrapped in high-strength carbon fibers for high strength gives tremendous advantage in weight reduction enabling almost double carrying capacity of the gas in same payload vehicle.
Cascades comply with strict national regulations, and are Equipped with pressure relief valves, safety valves, pressure gauges. Cylinders can hold gas pressure of 250 bar and used for CNG, CBG, Nitrogen gases.
True to it’s name, KAVACH Composite CNG cylinders from Supreme provides enhanced protection from rust increasing the life of the cylinder. The light weight construction delivers high performance with improved durability and reduced maintenance while offering superior storage efficiency.
Excellence in Cylinder Manufacture
Superior composite cylinders that have been rigorously
tested to ensure
unsurpassed quality
Features
The next-generation KAVACH CNG-265 cylinder is manufactured using high-grade carbon fiber and a tough epoxy resin system, applied through continuous filament winding technology. The cylinder design is validated through Finite Element Analysis (FEA) to ensure compliance with the highest
Lightweight Construction
Our 265L is 50% lighter than traditional Type 1 steel cylinders increasing the gas carrying to 9500 L on the same 10 MT standard truck payload
Free Liner
The impurities in CBG attack steel Type 1 cylinders whereas The KAVACH Type 4 cylinders have a special grade polymer liner that prevents internal rust and moisture degradation, leading to virtually maintenance-free operation and a longer service life
Longer Life
The Fully carbon-wrapped filament winding , gives a very high fatigue strength which can withstand cyclic loading during each filling cycle.
Higher Safety Standards
Unlike steel cylinders, splinters are not formed during bursting. The cylinders tested as per ISO 11119-3 standards undergo rigorous tests for lifecycle and safety.
Applications
Cylinders are best fit for Mobile Cascade in the CNG and CBG Industry
Automotive Fuel Storage
Transportation Cascades
Industrial Applications
Energy Applications
Commonly asked queries
What are the advantages of Supreme Type 4 CNG cylinder
Being lighter in weight, Supreme 265L Type 4 CNG cylinder carries double the gas in a cascade by reducing transportation costs by half and improving logistics.
The inner liner of the cylinder is made from HDPE which resists corrosion. Unpurified CNG consists of chemicals that attack the cylinder surface and drastically reduces the life of the cylinder.
What makes the Supreme CNG cylinders so strong
The cylinders are made from carbon fiber which is commonly used in avionics for light weight and strength purpose. The burst strength of Supreme CNG cylinder is about 800 bar.
Can the Supreme CNG cylinders be used on board
Currently, Supreme Kavach CNG cylinders are produced for cascade transportation.
What is the capacity of Supreme CNG cylinder
Currently, CNG cylinder offered are 265L. Very soon, 156L, 390L and 120L cylinders would be launched
Can Supreme CNG cylinders used to store Biogas
Yes. Supreme CNG cylinders are certified for Biogas, CNG and Nitrogen gas.
